Gerber Crescent 30 ¼ Mil Resolution Plotter
Gerber Escort 30 Automatic Film Loader
Fully Integrated Genesis & Pentalogix CAM Software & Network
CAM, ET, AOI, Laser Plotting & Drilling Network
HP 4V Laser Plotter
Made2Manage Barcode Job Tracking Enterprise Management System w/ Barcode Tracking
Kodak Kodamatic 66S+ Automatic Film Loader
5 CAM Stations with Design Rule Check
Test Fixturing Software
Net List Extraction Software
2 Mania Micronic 86, 200k spindles
Excellon System 2000
Milltronics VKM 3 – Milling Machine Center
3 Excellon Mark VI Drill, CNC 6
3 Excellon Mark VI Router, CNC 6
5 Independent Spindle Cooling Units
Aetna MG Pinner/De-Pinner
Diarco Corner Notcher
Bevelmaster Beveler
Quincy QGV-100 100HP Compressor
Quincy QED-500 Air Dryer
Ingersol Rand 75 HP Backup Compressor
Quincy Q235 65 HP Rotary Air Compressor
Wysong Hydraulic Laminate Shear
American Vacuum 15 Horse Central Vacuum System
Dayton Air 100 SCFM Aftercooler
Mach3 Labs Antares 700X - Precision X-Ray Drill
Edgemaster Semi-automatic Beveler
TMP Vacuum Lamination Press – 4 Opening
PHI 4 Opening Hot/Cold Press with Vacuum Assist
PHI 2 Opening Hot Press
PHI Vacuum Pump
9 Vacuum Frames
Carver 12 Ton Press
RAMCO Wide Belt Sander
Tadco 4140 Alloy Steel Combination Lamination Plates
304 Stainless Steel Separator Plates
Multiline Innerlayer Registration Punch
Multiline Core Punch & Depinner
Multiline Dual Camera Registration Up-Punch
Temperature & Humidity Controller
Environmentally Controlled Cold Storage, Prepreg
Grieve Oven With Chart Recorder
Do-All Thickness Measuring Granite Table
Real Time X-Ray
At MPCS, we are committed to preserving and protecting our environment through proactive management of our natural resources yielding superior air and water quality in our effluents. Additionally, we actively recycle over 90% of all consumable items purchased.
J-Mark Systems Water Treatment System
Serfilco 4 Cubic Foot Filter Press
Gravity Settler
Sludge Dryer
48' Semi Automatic Electroless Copper Line with Hoist
ENIG/Silver Line
Electrolytic Copper Panel Plating Line
(2) Electrolytic Copper Pattern Plating Lines
75 Gallon Deep Nickel Tank
300 Amp Rapid Remote Rectifier
Microplate Automatic Nickle/Gold Plating Line
Aldonex 10,000 Amp Remote Rectifier
Aldonex 3000 Amp Rectifier
(2) Aldonex 25 Amp Rectifiers
Serfilco Carbon and Polypro Filtration System
Oxide Conversion System
Technic Mini FFP Tab Plater
Tape Compressor for Nickle Gold Fingers
Calco Water Deionization System
AEM American Pro Wet Sanding Machine
Recirculating Filter Bed for Copper Recovery
Chemcut 107I Oscillating Scrubber
International Supplies Pumiflex SHD/A24
International Supplies Board Cleaner/Washer
Thin Laminate Capabilities
DEA 24" Conveyorized Developing and Rinsing Unit
Chemcut 547 Conveyorized Tin Stripping Line
Chemcut 547 Conveyorized Resist Stripping Line
Chemcut 547 XLI Alkaline Etching System
Hunt Chemical Automatic Controller
Continuous Chemistry Analysis/Balance
(2) Circuit Tech 70 Gallon Heaters
Anita Board Dryer
ASI Inner Layer Scrubber
Atlas High Pressure Sprayer
Chem Desmear & Etch Back Line (Premangenate)
Complete Argus 5000 Conveyorized Hot Air Leveling
Complete Argus 5000 Conveyorized Hot Air Leveling RoHS Lead Free Solder Line
In Line Pre-Clean, Fluxer and Post Clean Unit.
Fischerscope Multiple Measuring System
Real Time Plating Thickness Measuring
Perkin Elmer Model 280 Spectrophotometer – Atomic Absorption Unit
HACH DR/2000 Direct Reading Spectrophotometer
PH Meters, Laboratory Equipment
Chemisty Analysis Supplies
(2) Waage Electric 25 lb. Melting/Solder Pot
Buehler Ecomet Cross Sectioning Saw
Analytical Balance, Omega Meter 600
UPA Microderm MP-700
UPA Caviderm CD-8 with CPS-111B Probe Stand
Olympus Scope and Camera with Javelin Monitor
Coupon Punch
(3) Buehler Ecomet IV Variable Speed Polisher/Grinder
Perkin Elmer PinAAcle 500 - Automatic Absorption Spectrometer
Grieve Lab Oven
Orbotech Paragon 8800 LDI
Orbotech Sprint 120 Inkjet Legend Printer
Multiline OPE-9000 - 4 Camera Automatic Post Etch Punch
(3) Circuit Automation DP1500 LPI Solder Mask Coater
Dynachem Epic 110 Drying/Curing Tunnel Oven – Tack Cure
Dynachem Epic 110 Drying/Curing Tunnel Oven – Fixed Cure
Multiline Artwork Registration Film Punch
Colight 1630 Exposure Unit
Colight 1530 Exposure Unit
OLEC Accuprint AP30
(2) Colight 5kw 1330 Exposure Unit
(2) Dynachem Dry Film Soldermask Laminator
DuPont ASL-24 Yieldmaster Cut Sheet Laminator
DuPont HRL 24 Air Activated Laminator
LC-2400 Electro-Static Cleaner
(2) Autoroll Exacta 360
Burgess Industries 24' Ammonia Film Processor
Film Shears
Light Tables
X-Rite Densitometer
(3) Temp/Humidity Controllers
Anti-Static Auto Film Cleaner
Rich Automation Vertical Developer
Chemcut 547 LPI and Dry Film Solder Mask Developer
Multiline Opti-Line Film Punch
Multiline Registration Table
Nuarc FT40V3UPNS Flip Top Plate Maker
Nuarc Contact Vacuum Frame
EI-150 Digital Exposure Integrator & Timer
(3) Grieve Gas Ovens
Precision Quincy LPI Oven with Chart Recorder
(3) Blue Chip Precision Screen Presses / Backlight
Diamond Chase Screen Frames
Screen Reclamation Booth
Screen Reclamation Soak Tank
Power Spraying Unit
Screen Vacuum Unit
Screen Drying Cabinet
Ohaus Precision Scale
Newman ST-Tension Meter
Violux 3002 Exposure Unit / Vacuum Frame
Camtek Pheonix-HDI AOI System
Micro-Vu Excel 661UC
Mania AOI T8T DTS
Microcraft Flying Probe Electrical Tester EMMA EMX 6151
Microcraft Flying Probe Electrical Tester EMMA ELX 6146 with High Pot Capabilities
(3) Glenbrook X-Ray's
Buehler/Olympus Microscope & Software System
Oxford Instruments Advanced XRF Coating Thickness Measurement System
Micro-Vu Q16 Precision Measurement System
Polar Instruments 880 CITS Impedance Tester
Test Technologies 33,000 Test Point Universal Grid Tester
250 Volt Test Capacity
TTI Dual Access Tester
Fine Pitch SMD Test Probes
Hughes Constant Voltage Repair Station
High Pot Tester to 5000V
Cross Section Analysis Performed in House
